Dlink DVR-F2108-M5 8CH, 1 SATA H.265+ DVR

Availablity: In stock

₹11,805.00



Check if the product is available for delivery to your location


Share


Dlink DVR-F2108-M5 8CH, 1 SATA H.265+ DVR.

  • 8 CH, 1SATA.
  • Supports AHD/TVI/CVI/CVBS /IP Cameras.
  • Supports AHD/TVI Cameras upto 8MP.
  • Supports H.265+/H.265/H.264+/H.264.
  • Supports Smart Playback & Analytics.
  • Supports 2 extra IP ch.
  • Supports 3G/4G Wi-Fi.
  • Google drive & Dropbox Cloud Storage.
  • Supports video quality detection (VQD).

Technical Specifications

Brand D-Link
Model No DVR-F2108-M5
Model Name 8CH, 1 SATA H.265+ DVR
Video Input 8ch BNC interface (1.0Vp-p, 75 ?)
TVI / CVI /AHD TVI /AHD: 8MP,5MP,4MP,1080P, 720P / CVI: 4MP,1080P, 720P
IPC Up to 8ch 8MP
Audio Input 4-ch, RCA (2.0 Vp-p, 1 K?)
Two way Talk 1-ch, multiplex with Audio Input (RCA)
HDMI 1ch, resolution: 4K (3840×2160)/30Hz,1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz
VGA 1ch, resolution: 1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz
CVBS output 1-ch, PAL:704x576, NTSC:704x480
Audio Output 1-ch, RCA (Linear, 1k?)
Compression H.264/H.264+/ H.265/H.265+
Resolution 8MP@7fps,8MP lite@15fps,5MP@12fps,4MP@15fps,1080P/720P/960H/D1@25fps?P?/30fps?N?
Frame Rate(fps) 1fps-25fps (PAL) / 30fps (NTSC)
Video Bit Rate 11Kbps~ 10Mbps
Record Mode Manual, Schedule, Alarm
Audio Compression G.711a
Audio Bit Rate 64Kbps
Playback Mode Smart Playback/Normal/Time Division/ Label/ Event/ Picture Playback
Playback Rate 8CH 8MP lite/5MP/4MP/1080P Playback
Backup Mode USB Device/Network
Smart Detection for Analog 8CH line crossing detection, area Intrusion
Smart Playback for Analog line crossing detection, area Intrusion
Cloud Storage/Upgrade Support
Ethernet 1 RJ-45 10/100 Mbps self-adaptive Ethernet interface
Network Function HTTPs,HTTP,TCP/IP,IPv4,UPnP,Onvif2.6,RTSP,RTCP,UDP,SMTP,SNMP,Multicast,IGMP,NTP,DHCP,DNS,DDNS, FTP, P2P
Smart Phone IOS (iPhone, iPad), Android (Phone, Pad)
SATA 1 HDD
Capacity Up to 10TB capacity for each HDD
Serial Interface RS-485
USB Interface 2 × USB
Power Supply DC12V,2A
Power Consumption ?15W (without HDD)
Dimension 250 x 230 x 45mm
Weight 1.5kg
Mobile Software D-LINK SMART CCTV App
Desktop Software DSVS (D-LINK Smart Video Surveillance)
System Requirement for Web Interface IE
Warranty 5 Years Warranty
