Dlink DCS-F5614-L1 4MP Fixed IP Dome Camera

Availablity:In stock

₹4,975.00



Check if the product is available for delivery to your location


Share


Dlink DCS-F5614-L1 4MP Fixed IP Dome Camera.

  • 1/2.7" Progressive scan CMOS Sensor
  • 3.6mm Fixed lens
  • Up to 2560 x 1440 Full HD resolution
  • IR Range up to 30 Mtr.
  • DWDR, Day/Night (ICR), 3DNR, AWB, AGC, BLC
  • Support Defog, ROI, BLC, HLC UPnP-TM
  • Support smart functions
  • Support dual stream.

Technical Specifications

Brand Dlink
Model No DCS-F5614-L1
Model Name 4MP Fixed IP Dome Camera
Image Sensor 1/2.7" Progressive scan CMOS Progressive
Min. Illumination 0.01lux (Color), 0lux (IR on)
Shutter Time Auto/Manual, 1/3~1/10000s
Lens 3.6 mm@F2.0: horizontal FOV: 86°, vertical FOV:64.5°
Lens Mount M12
Day/Night IR cut filter with auto switch
Wide Dynamic Range DWDR
IR LEDs Length 30M
Smart IR Support
Video Compression H.264/H.264+/H.265/H.265+
H.264 / H.264+ Base/Main/High profile
H.265 / H.265+ Main profile
Video Bit Rate 11 Kbps ~ 8Mbps
Resolution MAX 4MP (2560×1440)
Main Stream 50Hz: 20fps 4MP (2560 × 1440), 25fps 3MP (2048 × 1536), 25fps 1080P (1920 × 1080), 25fps 960P (1280 × 960) 60Hz: 20fps 4MP (2560 × 1440), 30fps 3MP (2048 × 1536), 30fps 1080P(1920 × 1080), 30fps 960P(1280 × 960)
Sub Stream 50Hz: 25fps D1(704 × 576), 25fps, CIF (352 × 288), 60Hz: 30fps D1(704 × 480), 30fps, CIF(352 × 240)
Mobile Stream Brightness/Contrast/Saturation/Hue/Sharpness
Image Setting 50Hz:25fps CIF (352 × 288), 60Hz:30fps CIF (352 × 240)
HLC/BLC/ROI/Defog Support / On/Off, zone configurable/ Support / Support
Event Motion Detection, Video Shelter
Smart Functions Area Intrusion, Line crossing
Protocols TCP/IP,ICMP,HTTP,HTTPS,DHCP,DNS,DDNS,RTP, RTSP,RTCP,NTP,IGMP,UPnP,SMTP,UPnP-TM,P2P, Bonjour,IPV6
System compatibility Onvif 2.6, Profile S, CGI
Security User authentication, IP address filtering, Video mask
Mobile Surveillance iPhone, iPad, Android devices
Communication interface 1 RJ45 10M / 100M Ethernet Port
Operating Conditions -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply DC12V ± 10% )
POE Supply PoE (802.3af)
Power Consumption Max. 7W
Weather Proof IP66
Dimensions 102X90(H) mm
Weight 420g
warranty 2 Years
Mobile Software D-Link Smart CCTV App
Desktop Software DSVS (D-Link Smart Video Surveillance)
System Requirement for Web Interface IE
