Dlink DCS-F5712-L1 2MP Fixed IP Bullet Camera

Availablity:In stock


Check if the product is available for delivery to your location


Dlink DCS-F5712-L1 2MP Fixed IP Bullet Camera.

  • 1/2.9" Progressive scan CMOS Sensor
  • 3.6mm Fixed lens
  • Up to 1920 x 1080 Full HD resolution
  • IR Range up to 30 Mtr.
  • DWDR, Day/Night (ICR), 3DNR, AWB, AGC, BLC
  • Support Defog, ROI, BLC, HLC UPnP-TM
  • Support smart functions
  • Support dual stream

Technical Specifications

Brand Dlink
Model No DCS-F5712-L1
Model Name 2MP Fixed IP Bullet Camera
Image Sensor 1/2.9" Progressive scan CMOS Sensor
Min. Illumination 0.01lux (Color), 0lux (IR on)
Shutter Time Auto/Manual, 1/3~1/10000s
Lens 3.6 mm@F2.0: horizontal FOV:82 °, vertical FOV:44°
Lens Mount M12
Day/Night IR cut filter with auto switch
Wide Dynamic Range DWDR
IR LEDs Length 30M
Smart IR Support
Video Compression H.264/H.265
H.264 / H.264+ Base/Main/High profile
H.265 / H.265+ Main profile
Video Bit Rate 11 Kbps ~ 5Mbps
Resolution Max 1920 x 1080
Main Stream 50HZ:20fps 2MP (1920*1080) ?25fps 1.3MP (1280*960) ?25fps 1MP (1280*720) 60HZ:20fps 2MP (1920*1080) ?30fps 1.3MP (1280*960) ?30fps 1MP (1280*720)
Sub Stream 50Hz:25fps D1(704 × 576), 25fps CIF (352 × 288), 60Hz:30fps D1(704 × 480), 30fps CIF (352 × 240)
Image Setting Brightness/Contrast/Saturation/Hue
HLC/BLC/ROI/Defog Support / On/Off, zone configurable/ Support / Support
Event Motion Detection, Video Shelter
Smart Functions Area Intrusion, Line crossing
System compatibility Onvif 2.6, Profile S, CGI
Security User authentication, IP address filtering, Video mask
Mobile Surveillance iPhone, iPad, Android devices
Communication interface 1 RJ45 10M / 100M Ethernet Port
Operating Conditions -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply DC12V ± 10% )
POE Supply PoE (802.3af)
Power Consumption Max. 6.5W
Weather Proof IP66
Dimensions 187*64*64mm
Weight 300g
warranty 2 Years
Mobile Software D-Link Smart CCTV App
Desktop Software DSVS (D-Link Smart Video Surveillance)
System Requirement for Web Interface IE
