HPE Aruba JL677A 6100 24G CL4 PoE+ 4SFP+ 370W Managed Enterprise Switch
Check if the product is available for delivery to your location
HPE Aruba JL677A 6100 24G CL4 PoE+ 4SFP+ 370W Managed Enterprise Switch
Key Features
-
✅ 24x Gigabit RJ-45 Ports with Class 4 PoE+ (370W Total Budget)
-
✅ 4x SFP+ Uplink Ports (1/10GbE) for high-speed fiber connectivity
-
✅ Enterprise-Grade Layer 2+ Switching with VLAN, ACLs, QoS & static routing
-
✅ Powered by Aruba AOS-CX OS for intelligent, cloud-ready networking
-
✅ Advanced Security – MAC authentication, RADIUS, TACACS+
HPE Aruba JL677A 6100 24G CL4 PoE+ 4SFP+ 370W Managed Enterprise Switch
The HPE Aruba JL677A is a reliable, next-generation Layer 2+ managed switch designed to deliver intelligent power and connectivity at the network edge. With 24 Gigabit RJ-45 ports supporting PoE+ (up to 370W total), this switch provides seamless data and power delivery for your wireless access points, IP phones, security cameras, and IoT devices—making it a perfect fit for modern digital workplaces and enterprise campuses.
Integrated with 4 high-speed SFP+ uplinks, it enables smooth fiber backbone connectivity, while Aruba’s powerful AOS-CX operating system brings cloud-managed intelligence, automation, and visibility to your access layer. The JL677A combines performance and simplicity in one platform—no hidden licenses, no unnecessary complications.
Key Features
-
✅ 24x Gigabit RJ-45 Ports with Class 4 PoE+ (370W Total Budget)
-
✅ 4x SFP+ Uplink Ports (1/10GbE) for high-speed fiber connectivity
-
✅ Enterprise-Grade Layer 2+ Switching with VLAN, ACLs, QoS & static routing
-
✅ Powered by Aruba AOS-CX OS for intelligent, cloud-ready networking
-
✅ Advanced Security – MAC authentication, RADIUS, TACACS+
-
✅ Centralized Management via Aruba Central, Web GUI, CLI & REST API
-
✅ Integrated Analytics & Automation
-
✅ No Licensing Required – All features included from day one
Why Choose Aruba JL677A PoE+ Switch?
The Aruba 6100 JL677A is a high-performance, cloud-managed access switch built for modern enterprise edge deployments. With 24 Gigabit ports supporting PoE+ and a total power budget of 370W, this switch effortlessly powers access points, IP cameras, VoIP phones, and IoT devices—while ensuring rock-solid data transmission.
Equipped with 4 SFP+ uplinks, it enables high-speed fiber backhaul and redundancy. The Aruba AOS-CX operating system brings enterprise-grade capabilities like programmability, telemetry, and network automation to your fingertips. Plus, it includes a lifetime warranty with no hidden costs—no separate software licenses needed.
Why Choose Supreme Computers?
With over 30 years of expertise, Supreme Computers is your trusted IT partner in Chennai. We provide reliable power solutions, computing systems, and enterprise-grade hardware to businesses, homes, and institutions across India. As an authorized reseller for top brands, we assure genuine products, expert advice, and dedicated support.
Contact Us
Email: esupport@supremeindia.com
Website: www.supremeindia.com
Location: Chennai, India
Call/WhatsApp: 7305844492 / 9500017188
Technical Specifications
| Manufacturer | Aruba |
| Brand | Aruba |
| Model No | JL677A |
| Features | Flow Control, Bootp Support, Arp Support, Vlan Support, Diffserv Support, Ipv6 Support, Sntp Support, Sflow, Multiple Spanning Tree Protocol (mstp) Support, Trivial File Transfer Protocol (tftp) Support, Mld Snooping, Lacp Support, Lldp Support, Port Based Access Control, Dhcp Client, Energy Efficient Ethernet, Management Information Base (mib), Network Access Control (nac), Neighbor Discovery Protocol (ndp), Snmp Support, Internet Control Message Protocol (icmp), Entitymib, Dns Client, Lldp-med, User Datagram Protocol (udp), Rapid Reconfiguration Of Spanning Tree (rstp), Ipv6 Addressing |
| Interfaces | 24 x 10/100/1000 Base-T RJ-45 | 4 x 1/10Gbit LAN SFP+ | 1 x USB-C console | 1 x USB Type A |
| Compliant Standards | IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.3az |
| Processor | Dual Core ARM Cortex A9 @ 1016 Mhz |
| RAM | 4 GB DDR3 SDRAM |
| Flash Memory | 16 GB eMMC |
| Form Factor (Hubs & Switches) | Rack-mount |
| Routing Protocol | IGMPv2, IGMPv3 |
| Encryption Algorithm | SSL |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| MAC Address Table Size | 8192 entries |
| Manageable | Yes |
| Device Type | Switch - 24 Ports - L3 - Managed - Stackable |
| Enclosure Type | Side To Side Airflow Rack-mountable 1u |
| Subtype | 10 Gigabit Ethernet |
| Ports | 24x ports 10/100/1000BASE-T ports 4x 1G/10G SFP ports |
| Performance | Switching capacity: 128 Gbps | Throughput: 95.2 Mpps | Latency (1 Gbps): 1.5 µs | Latency (10 Gbps): 1.8 µs |
| Capacity | Switched virtual interfaces (SVIs): 16 | ARP entries: 1024 | IPv4 routes (Unicast): 512 | IPv6 routes (Unicast): 512 | IGMP groups: 512 | MLD groups: 512 | IPv4 ACL entries (ingress): 256 | IPv6 ACL entries (ingress): 128 | MAC ACL entries (ingress): 256 |
| Latency | 1 Gbps: 1.5 Sec , 10 Gbps: 1.8 Sec |
| Differentiator | The Aruba CX 6100 Switch Series delivers entry level, reliable, and convenient Layer 2 wired access connectivity ideal for branch offices, mid-market enterprise, and SMBs. This model has 24x 10/100/1000BASE-T and 4x 1G/10G SFP ports. |
| Power consumption | Max Power (w/o PoE): 32.7W |
| Input voltage | 100-127 VAC / 200-240 VAC |
| Switching capacity | 128 Gbps |
| Throughput | 95.2 Mpps |
| Memory and processor | Dual Core ARM Cortex A9 @ 1016 Mhz 4 GB DDR3, maximum, depending on model 16 GB eMMC |
| Power supply name | Internal |
| Power Supply Type | Internal |
| Connectivity | 24 x 10/100/1000 Base-T RJ-45 | 4 x 1/10Gbit LAN SFP+ | 1 x USB-C console | 1 x USB Type A |
| PoE capability | 370W Class 4 PoE/PoE+ |
| Ventilation | Fan |
| Color | Black |
| Weight | 4.2 kg (9.24 lbs) |
| Product Dimensions | 4.4 x 44.2 x 26.8 cm (1.73 x 17.4 x 10.56 in) |
| Warranty | Limited Lifetime Warranty |
